Description
The Zehnder ComfoWell 625 is a modular air distribution system consisting of attenuators, fine grade filters and active carbon filters all integrated for use with a rigid or semi-rigid ductwork approach. The cases are 625mm wide and can be used to make 11 or 12 ComfoTube connections. The systems compact dimensions ensure good sound absorption and also make it easy to clean. Rigid pipe can be connected to the end plate securely by utilising the gasket seal connection. All other components are fitted using the RapidLock® connections to quickly form an air tight and robust seal by simply push-fitting the semi-rigid ductwork. Noise reduction can be improved by combining two attenuators together. Filters are available in ISO ePM1 (F7), ISO ePM1 (F9) grade in addition to an odour neutralising active carbon filter.
- Modular air distribution system
- Dimensions: W: 625mm; H: 233mm
- Recommended max. air volume: 133.3l/s (480 m³/h) at normal ventilation level
- Housing: Galvanised metal
- Fire rating to ISO13501: C
- Easy to assemble due to modular and compact design
- All connections with rubber gaskets and RapidLock®
- Attenuated inner lining: Closed-cell melamine resin foam (manifold box and attenuator)
- The mounting plate can be connected to the manifold box, or directly to the attenuator or the filter housing.
