Description
The Zehnder ComfoPost family are a series of air to water exchangers for use with ComfoWell air distribution connections. The ComfoWell connections allows for selection flexibility, offering a range of rigid circular ductwork or Zehnder ComfoTube semi-rigid ductwork to be attached.
The ComfoPost is available in four models to heat or cool the air supplied by the Zehnder ventilation system. The ComfoPost units are suitable for a wide range of airflows up to 166l/s (600m3hr).
The units are made of steel with aluminium and copper pipe forming the heating and cooling coils and are maintenance free.
- Ideal for use with reversible heat pumps or chillers to meet SAP 10 or TM59 overheating demands
- Low pressure losses
- Filtered fresh supply air, not recycled stale air
- Suitable for use with the unique modular ComfoWell manifolds
- Suitable for horizontal or vertical installation
- Condensation water tray and drain as standard
CW6 – suitable for airflows up to 83.3l/s (300m3hr). (Comfowell 320 compatible)
CW8 – suitable for airflows up to 111.1l/s (400m3hr) (Comfowell 420 compatible)
CW10 – suitable for airflows up to 138.9l/s (500m3hr) (Comfowell 520 compatible)
CW12 – suitable for airflows up to 166l/s (600m3hr) (Comfowell 625 compatible)
