Description
The Zehnder Comfoair 70 is a de-centralised ventilation unit with heat and humidity recovery using synchronous supply and extract air operation. It is often used in apartment renovations as well as in new PassivHaus residential builds. The Comfoair 70 de-centralised ventilation unit is suitable for venting individual rooms. An enthalpy exchanger, which ensures a high degree of heat and humidity recovery, is standard in the unit, which has a positive effect on the room humidity and therefore provides a comfortable indoor climate.
Air flow range 20–40 m³/h
Heat recovery rate HR = 85%
Specific electric power Pel,spec = 0.24 Wh/m³
Humidity recovery x = 64%
Advantages
- The Comfoair 70 provides exceptionally good indoor climate.
- High energy efficiency and maximum cleanliness due to washable enthalpy exchanger.
- Continuous supply air/extract air operation for continuous heat and humidity recovery.
- Demand control using optional humidity and CO2 sensors.
- Quiet operation due to high-quality radial fans and good insulation.
- Great flexibility due to range of optional components.
- Simple and quick installation with minimal intrusion into the living space.
- Attractive and discreet appearance: the outside wall panel can be painted over to match the colour of the wall.
- No condensate drain required due to the enthalpy exchanger.
- Adjoining room connection for good airflow and flexible planning
- Window reveal module with discreet outside and exhaust air grilles for almost invisibly transported air.
IMPORTANT
PLEASE NOTE A WALL MOUNTING DUCT IS REQUIRED WITH THESE UNITS AND IT NEEDS TO BE ORDERED SEPARATELY AS THERE ARE TWO SIZES (600mm & 900mm) PLEASE SELECT ONE BELOW.
Delivery typically 2-3 days subject to stock
