Description

Zehnder ComfoAir 200

Heat recovery unit designed to enable better and easier specification of ventilation in new properties due to its versatility. It can be left or right handed in addition to being ceiling or wall mounted. It contains features such as its automatic true summer by-pass, high heat recovery efficiency and upgradable high grade filters providing a comfortable, healthy and energy-efficient indoor climate.

Airflow range of 60-150m³/hr. 92% heat recovery efficiency

• 100% automatic summer by-pass.
• Left or right hand confirguration in one unit.
• Flexible installation options either ceiling or wall mountable.
• Constant volume motors to maintain commissioned flow rates.
• Tool free filter access.
• Volt free contact boost capability.
• BMS capability via RS232 protocol.
• RFZ wireless connectivity option.
• 0-10V input option.
• ISO ePM1 >55% (F7) filter option.
• Internal pre-heater option.
• Enthalpy cube option.
• Passivhaus certified

Air flow range                     60-150 m³/h
Heat recovery rate              ηnHR = 92%
Specific electric power        Pel,spec = 0.42 Wh/m³
