Steico Internal Wet Square Edge

Steico Internal Wet Square Edge

Description

STEICO Internal Wet is a rigid natural wood fibre insulation board with a square edge profile manufactured in accordance with EN13171. Thermal conductivity of 0.038W/mK.

Wood for STEICO Internal Wet comes from sustainable forestry and is independently certified by the FSC®
Applications

  •     Interior insulation for floors or roofs, insulation between rafters
  •     Insulation under a screed
  •     Insulation for timber structures



Made in the EU

Produced and supervised according to EN 13171
Board designationWF – EN 13171 – T4 – CS(10 Y)50 –
TR2,5 – AFr 100
Edge designSquare edge
Fire class according to EN 13501-1E
Declared thermal conductivity λD [ W / ( m*K )]0.038
Declared thermal resistance RD [( m2*K ) / W]0.5 / 1.0 / 1.5 /2.0 / 2.5 / 3.0 / 3.5 / 4.0
Density [kg / m3]ca. 160
Water vapour diffusion resistance factor μ5
Sd value [m]0.1 / 0.2 / 0.3 / 0.4 / 0.5 / 0.6 / 0.7 / 0.8
Specific heat capacity [J / (kg*K)]2100
Minimum compression strength at 10% deformation σ10 [N / mm2]0.05
Minimum compression strength [kPa]50
Tensile strength perpendicular to face ^ [kPa]≥ 2.5
Manufacturing processWet process / utilises the wood's own lingnin for panel bonding
Raw materialwood fibre,  bond between layers
Bonded carbon [kg CO 2 equivalent./m 3 ] (approx.)270

Steico Internal Wet 1200x380x40mm board covering 0.456m²
Steico Internal Wet 1200x380x40mm board covering 0.456m²
SKU: 100222
£5.30 ex VAT

In stock

Steico Internal Wet 1200x380x40mm pallet (of 150) covering 68.4m²
Steico Internal Wet 1200x380x40mm pallet (of 150) covering 68.4m²
SKU: 100222P
£795.60 ex VAT

In stock

Steico Internal Wet 1200x380x60mm board covering 0.456m²
Steico Internal Wet 1200x380x60mm board covering 0.456m²
SKU: 100223
£7.93 ex VAT

In stock

Steico Internal Wet 1200x380x60mm pallet (of 99) covering 45.14m²
Steico Internal Wet 1200x380x60mm pallet (of 99) covering 45.14m²
SKU: 100223P
£785.27 ex VAT

In stock

Steico Internal Wet 1200x380x80mm board covering 0.456m²
Steico Internal Wet 1200x380x80mm board covering 0.456m²
SKU: 100224
£10.60 ex VAT

In stock

Steico Internal Wet 1200x380x80mm pallet (of 75) covering 34.2m²
Steico Internal Wet 1200x380x80mm pallet (of 75) covering 34.2m²
SKU: 100224P
£794.70 ex VAT

In stock

Steico Internal Wet 1200x380x100mm board covering 0.456m²
Steico Internal Wet 1200x380x100mm board covering 0.456m²
SKU: 100225
£13.27 ex VAT

In stock

Steico Internal Wet 1200x380x100mm pallet (of 60) covering 27.36m²
Steico Internal Wet 1200x380x100mm pallet (of 60) covering 27.36m²
SKU: 100225P
£796.32 ex VAT

In stock
