Name: Steico Flex 036
Brand: Steico
Availability: InStock

Description

Steicoflex 036 Thermal Insulation

Steico flex 036 is an environmentally friendly flexible thermal insulation manufactured from natural wood fibres with an improved thermal conductivity of 0.036 W/mK.

Flexible insulation
Excellent insulation properties in winter and summer
Water vapour open for a healthy indoor climate
Climate regulating with a high sorption capacity
Contributes to a healthyindoor climate
Reduces thermal bridges
Non irritant
Easily cut and handled
Semi rigid for ease of installation
Steico flex 036 insulation is Ecologically and environmentally certified
Recyclable

Price per pack

FSC - Forest Stewardship Council CE marked product

Made in the EU

Technical Specification
Produced and supervised according to EN 13171
Board designation	WF – EN 13171 – T3 – TR1 – AF5 – MU2
Fire class according to EN 13501-1	E
Building materials class acc. to DIN 4102	B2
Declared thermal conductivity λD [ W / ( m * K )]	0.036
Declared thermal resistance RD [( m2 * K ) / W]	1,10(40) / 1,35(50) /1,65(60) / 2,20(80) / 2,75(100) / 3,30(120) /3,85(140)
Thickness [mm]	40 / 50 / 60 / 80 / 100 / 120 / 140 / 160 / 180 / 200
Density [kg / m3]	ca.60
Water vapour diffusion resistance value μ	2
Specific heat capacity c [J / (kg * K)]	2100
Declared level of airflow resistance [( kPa * s ) / m2]	≥ 5
Ingredients	wood fibres, polyolefin fibres, ammonium phosphate
Waste code (EAK)	030105 / 170201

The standard board size for STEICOflex is designed so that the batt will be a friction fit between 38mm wide timber studs spaced at 600mm increments. A 375mm wide batt is also available to fit between studs spaced at 400mm centres.

The maximum span of STEICOflex is dependant on the thickness of the insulation batt used. The following maximum spans can be used:
